MDT – Combi-Presence Detector 360° with room climate sensors

Description

KNX Combi-Presence Detector with constant light control and Air-quality signal light function

Product features

• KNX Combi Presence Detector 360° with  room climate sensors
• Passive infrared presence detector with 3 sensors for ceiling installation
• Constant light control for up to 3 light strips
• Sensors for CO2 and VOC mixed gas concentration, relative humidity and temperature
• Upper and lower threshold value adjustable for  each measured value
• Visualisation of the air quality by means of an internal RGB LED
• Air-quality lamp function adjustable to CO2 or VOC sensor with 4 colour channels and adjustable 1 bit / scene / RGB or HSV output objects
• Detection area 360°, coverage Ø 11 m, presence Ø 5 m
• 1 HVAC and 1 alarm / notification channel
• Adjustable sensitivity and presence sensitivity for day, night and alarm
• Short-time presence to reduce stopping time Block and forced setting functions with release time
• Air-quality control function adjustable as step / PI controller for CO2 or VOC sensor
• Integrated room temperature controller with externally adjustable setpoint and selectable control parameters
